Specifications
- Product codeC53UiG+5HPaxD2HPaxD
- Suggested price$139.00
- ArchitectureARM 64bit
- CPUIPQ-6010
- CPU core count4
- CPU nominal frequencyauto (864 – 1800) MHz
- CPU Threads count4
- Switch chip modelIPQ-6010
- RouterOS license6
- Operating SystemRouterOS v7
- Size of RAM1 GB
- Storage size128 MB
- Storage typeNAND
- MTBFApproximately 200’000 hours at 25C
- Tested ambient temperature-40°C to 70°C
Wireless capabilities
- Wireless 2.4 GHz Max data rate574 Mbit/s
- Wireless 2.4 GHz Number of chains2
- Wireless 2.4 GHz standards802.11b/g/n/ax
- Antenna gain dBi for 2.4 GHz3.3
- Wireless 2.4 GHz chip modelQCN-5022
- Wireless 2.4 GHz generationWi-Fi 6
- Wireless 5 GHz Max data rate1200 Mbit/s
- Wireless 5 GHz Number of chains2
- Wireless 5 GHz standards802.11a/n/ac/ax
- Antenna gain dBi for 5 GHz5.5
- Wireless 5 GHz chip modelQCN-5052
- Wireless 5 GHz generationWi-Fi 6
- WiFi speedAX1800
Ethernet
- 10/100/1000 Ethernet ports4
- Number of 1G Ethernet ports with PoE-out1
- Number of 2.5G Ethernet ports1
Peripherals
- Number of USB ports1
- USB Power ResetYes
- USB slot typeUSB 3.0 type A
- Max USB current (A)1.5
Powering
- Number of DC inputs2 (DC jack, PoE-IN)
- DC jack input Voltage12-28 V
- Max power consumption38 W
- Max power consumption without attachments15 W
- PoE inPassive PoE
- Cooling typePassive
- PoE in input Voltage18-28 V
PoE-out
- PoE-out portsEther 1
- PoE outPassive PoE
- Low voltage PoE-Out current limit0.625 A
- Max total out (A)0.625 A
- Total output current0.625
- Total output power15
Certification & Approvals
- CertificationCE, FCC, IC, EAC, ROHS
- IP20
